The coil cut to length line is a production line that processes steel coils into sheet metal of various sizes and thicknesses. It typically includes a shearing machine, a leveling machine, a punching machine, and other auxiliary equipment.
The coil cutting line uses a shearing machine to cut the steel coil into sheet metal of the desired length and width. The leveling machine is used to level the surface of the sheet metal to remove any unevenness or waviness, ensuring a flat and smooth surface. The punching machine is used to punch holes or cutouts in the sheet metal according to the desired pattern or design.
The coil cutting line has the following advantages:
High production efficiency: The line can process large quantities of steel coils quickly and continuously, reducing production time and costs.
Good quality: The line uses advanced equipment and control technology to ensure precise cutting and high-quality sheet metal products.
Flexible processing: The line can process different sizes, thicknesses, and grades of steel coils, allowing for a wide range of sheet metal products to be produced.
Low cost: The line can process scrap steel coils, reducing material costs and waste.
The coil cutting line is suitable for processing steel coils into sheet metal products that require precision cutting, punching, and leveling, such as automobiles, appliances, and construction materials. It is widely used in the automotive, home appliance, building material, and other industries.
■Technical Parameters：
1.Material Parameters
Material CR steel coil σs=240Mpa
Thickness： 0.5~3mm
Width： 500~1250mm
Coil OD Φ900~Φ1300mm
Coil ID Ø508 / Ø610
Max Coil Weight 15t
3.Cutting parameters
Feeding tolerance ± 1mm (Length<1000mm)
Diagonal tolerance ± 1.5mm (length<1000mm)
Leveling tolerance ±2.0mm/m2
Stacking length 6000mm max
Working height +1000mm
